Технические характеристики
| Width, mm | 325 |
| Height, mm | 325 |
| Depth, mm | 154 |
| Suitable for 19 inch rack mounting | No |
| EMC-version | No |
| Degree of protection (IP) | IP54 |
| Rated power, W | 136 |
| Roof ventilator | No |
| Built as slide-in ventilator | Yes |
| Volume flow, freeblowing, m³/h | 670 |
| Air circulator | No |
| Wall build in | Yes |
| Operating voltage at AC 50 Hz, V | 230...230 |
| Operating voltage at AC 60 Hz, V | 230...230 |
| Voltage type | AC |
| Mounting method | Snap mounting |
| Number of fans | 1 |
| With filter | Yes |
| RAL-number | 7035 |
| With protective cover | Yes |
| Noise emission, dB(A) | 70 |
| Colour | Grey |
| Product type | Fan |
| Mounting type | Wall-mounted |
| Rated operating voltage V, ~, Hz | 230 V, 1 p, 50/60 Hz |
| Size | Size 20, 325 x 325 |
| EMC-version | No |
| Code of ventilation grille | R5RF20 |
| External dimensions (W x H x D), mm | 325 x 325 x 154 |
| Maximum installation depth, mm | 139.4 |
| Required mounting cut-out (W x H), mm | 292 x 292 |
| Degree of protection | IP54 |
| Optionally degree of protection | IP55, IP56 |
| Material | ABS plastic, PC, UL94V0 |
| Operating temperature range, ˚C | -10…+55 |
| Storage temperature range, ˚C | -40…+70 |
| Noise level, dB(A) | 70 |
| Rated current, A | 0.61 |
| Rated power consumption, W | 136 |
| Maximum static pressure, Pa | 120 |
| Service life (MTBF), h | 50000 |
| Filter class | G3 |
| Color | RAL 7035, light grey |
| Weight, kg | 3.1 |
| Unimpeded air flow, m3/h | 670 |
На нашем сайте вы всегда можете купить в России с доставкой по всем регионам России.
Дата обновления информации о товаре 2026-02-18 14:16:05
Технические характеристики 62900
Характеристики
- Air circulator
- No
- Built as slide-in ventilator
- Yes
- Code of ventilation grille
- R5RF20
- Color
- RAL 7035, light grey
- Colour
- Grey
- Degree of protection
- IP54
- Degree of protection (IP)
- IP54
- Depth, mm
- 154
- EMC-version
- No
- External dimensions (W x H x D), mm
- 325 x 325 x 154
- Filter class
- G3
- Height, mm
- 325
- Material
- ABS plastic, PC, UL94V0
- Maximum installation depth, mm
- 139.4
- Maximum static pressure, Pa
- 120
- Mounting method
- Snap mounting
- Mounting type
- Wall-mounted
- Noise emission, dB(A)
- 70
- Noise level, dB(A)
- 70
- Number of fans
- 1
- Operating temperature range, ˚C
- -10…+55
- Operating voltage at AC 50 Hz, V
- 230...230
- Operating voltage at AC 60 Hz, V
- 230...230
- Optionally degree of protection
- IP55, IP56
- Product type
- Fan
- RAL-number
- 7035
- Rated current, A
- 0.61
- Rated operating voltage V, ~, Hz
- 230 V, 1 p, 50/60 Hz
- Rated power consumption, W
- 136
- Rated power, W
- 136
- Required mounting cut-out (W x H), mm
- 292 x 292
- Roof ventilator
- No
- Service life (MTBF), h
- 50000
- Size
- Size 20, 325 x 325
- Storage temperature range, ˚C
- -40…+70
- Suitable for 19 inch rack mounting
- No
- Unimpeded air flow, m3/h
- 670
- Voltage type
- AC
- Volume flow, freeblowing, m³/h
- 670
- Wall build in
- Yes
- Weight, kg
- 3.1
- Width, mm
- 325
- With filter
- Yes
- With protective cover
- Yes
