Артикул: 70776
В наличии
ДКС
Цена по запросу Стоимость зависит от выбранного способа оплаты и количества товара.
Не отвечаем 5 минут — скидка на весь заказ!
Нужна скидка? Звони — сделаем лучшее предложение
Работаем по всей России
Возможны самовывоз и доставка по всей территории России
Надежность
Профессиональная поддержка
Технические характеристики
| Mounting method | Snap mounting |
| Width, mm | 150 |
| Height, mm | 150 |
| Suitable for 19 inch rack mounting | No |
| Number of fans | 1 |
| Degree of protection (IP) | IP54 |
| With filter | Yes |
| Rated power, W | 22 |
| Roof ventilator | No |
| Volume flow, freeblowing, m³/h | 44 |
| Wall build in | Yes |
| Operating voltage at AC 50 Hz, V | 115...115 |
| Operating voltage at AC 60 Hz, V | 115...115 |
| Voltage type | AC |
| RAL-number | 7035 |
| With protective cover | Yes |
| Noise emission, dB(A) | 45 |
| Depth, mm | 76 |
| EMC-version | No |
| Built as slide-in ventilator | Yes |
| Air circulator | No |
| Colour | Grey |
| Product type | Fan |
| Mounting type | Wall-mounted |
| Rated operating voltage V, ~, Hz | 115 V, 1 p, 50/60 Hz |
| Size | Size 12, 150 x 150 |
| EMC-version | No |
| Code of ventilation grille | R5RF12 |
| External dimensions (W x H x D), mm | 150 x 150 x 76 |
| Maximum installation depth, mm | 62.9 |
| Required mounting cut-out (W x H), mm | 124,5 x 124,5 |
| Degree of protection | IP54 |
| Optionally degree of protection | IP55, IP56 |
| Material | ABS plastic, PC, UL94V0 |
| Operating temperature range, ˚C | -10…+55 |
| Storage temperature range, ˚C | -40…+70 |
| Noise level, dB(A) | 45 |
| Rated current, A | 0.26 |
| Rated power consumption, W | 22 |
| Maximum static pressure, Pa | 55 |
| Service life (MTBF), h | 50000 |
| Filter class | G3 |
| Color | RAL 7035, light grey |
| Weight, kg | 0.8 |
| Unimpeded air flow, m3/h | 44 |
На нашем сайте вы всегда можете купить в России с доставкой по всем регионам России.
Дата обновления информации о товаре 2026-02-18 14:17:15
Технические характеристики 70776
Характеристики
- Air circulator
- No
- Built as slide-in ventilator
- Yes
- Code of ventilation grille
- R5RF12
- Color
- RAL 7035, light grey
- Colour
- Grey
- Degree of protection
- IP54
- Degree of protection (IP)
- IP54
- Depth, mm
- 76
- EMC-version
- No
- External dimensions (W x H x D), mm
- 150 x 150 x 76
- Filter class
- G3
- Height, mm
- 150
- Material
- ABS plastic, PC, UL94V0
- Maximum installation depth, mm
- 62.9
- Maximum static pressure, Pa
- 55
- Mounting method
- Snap mounting
- Mounting type
- Wall-mounted
- Noise emission, dB(A)
- 45
- Noise level, dB(A)
- 45
- Number of fans
- 1
- Operating temperature range, ˚C
- -10…+55
- Operating voltage at AC 50 Hz, V
- 115...115
- Operating voltage at AC 60 Hz, V
- 115...115
- Optionally degree of protection
- IP55, IP56
- Product type
- Fan
- RAL-number
- 7035
- Rated current, A
- 0.26
- Rated operating voltage V, ~, Hz
- 115 V, 1 p, 50/60 Hz
- Rated power consumption, W
- 22
- Rated power, W
- 22
- Required mounting cut-out (W x H), mm
- 124,5 x 124,5
- Roof ventilator
- No
- Service life (MTBF), h
- 50000
- Size
- Size 12, 150 x 150
- Storage temperature range, ˚C
- -40…+70
- Suitable for 19 inch rack mounting
- No
- Unimpeded air flow, m3/h
- 44
- Voltage type
- AC
- Volume flow, freeblowing, m³/h
- 44
- Wall build in
- Yes
- Weight, kg
- 0.8
- Width, mm
- 150
- With filter
- Yes
- With protective cover
- Yes
