Технические характеристики
| Mounting method | Snap mounting |
| Width, mm | 540 |
| Height, mm | 128 |
| Depth, mm | 390 |
| Suitable for 19 inch rack mounting | Нет |
| Number of fans | 1 |
| EMC-version | Нет |
| Degree of protection (IP) | IP44 |
| With filter | Да |
| Rated power, W | 160 |
| Roof ventilator | Да |
| Built as slide-in ventilator | Нет |
| Volume flow, freeblowing, m³/h | 1500 |
| Air circulator | Нет |
| Wall build in | Нет |
| Operating voltage at AC 50 Hz, V | 230 |
| Operating voltage at AC 60 Hz, V | 230 |
| Voltage type | AC |
| RAL-number | 7035 |
| With protective cover | ДА |
| Noise emission, dB(A) | 74 |
| Colour | Grey |
| Product type | Fan |
| Mounting type | Roof-mounted |
| Rated operating voltage V, ~, Hz | 230 V, 1 p, 50/60 Hz |
| Size | Roof-mounted, 540 x 128 x 390 |
| EMC-version | No |
| Code of ventilation grille | 2 x R5RF20 |
| External dimensions (W x H x D), mm | 540 x 128 x 390 |
| Maximum installation depth, mm | 38 |
| Required mounting cut-out (W x H), mm | 380 x 260 |
| Degree of protection | IP44 |
| Optionally degree of protection | - |
| Material | Steel sheet |
| Operating temperature range, ˚C | -20…+50 |
| Storage temperature range, ˚C | -20…+50 |
| Noise level, dB(A) | 74 |
| Rated current, A | 0.7 |
| Rated power consumption, W | 160 |
| Maximum static pressure, Pa | - |
| Service life (MTBF), h | 50000 |
| Filter class | - |
| Color | RAL 7035, light grey |
| Weight, kg | 11.3 |
| Unimpeded air flow, m3/h | 1500 |
| Power supply connection | Cable length 1 500 mm |
| Cable cross-section | 3 х 1 mm² |
